| 顯示內容 | 產品圖 | 型號 | 尺寸 (寸) |
外形尺寸 (mm) |
視域尺寸 (mm) |
引腳 | 視角 | 接口 | IC Part No. | 亮度 (cd/m2) |
溫度 (°C) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 480(RGB)×480 |  |
QT-T21ST40ZP01 | 2.10 | 56.18*59.71*2.3 | 53.28*53.28 | 40PIN | ALL VIEW | 3SPI+18RGB | ST7701S | 300Cd/m3 | - 20~+70°C |
| 240RGB*320 |  |
QT-T20ST22LP01 | 2.00 | 36.05(W)*51.8(H)*2.8(T) | 30.24(W)*40.32(H) | 22PIN | ALL VIEW | MCU 8 bit Interface | ST7789V | 220Cd/m3 | - 20~+70°C |
| 960 (H)×240 (V) |  |
QT-T20NT40ZP01 | 2.00 | 46.1(W)×40.96(H)*×2.53(D) | 40.8(W)×30.6(H) | 40PIN | TN-12 o`clock | 6-bits data bus (RGB | ILI9342 | - 20~+70°C | |
| 176(RGB) * 220 |  |
QT-T20NT20P01 | 2.00 | 51.30 (W) * 37.68 (L) * 2.2(H) | 39.60 (W) * 31.68 (L) | 20pin | TN-12 o`clock | MCU | ST7775R | 250Cd/m3 | - 20~+70°C |
| 240RGB*320 |  |
QT-T20SH12ZP02 | 2.00 | 34.70(H)*47.95(V)*2.20 | 30.6(W)*40.8(H) | 12pin | All View | SPI | 7789V | 250Cd/m3 | - 20~+70°C |
| 240RGB*320 |  |
QT-T20SH12ZP01 | 2.00 | 34.60(W)*47.80(H)*1.90(T) | 30.6(W)*40.8(H) | 12pin | All View | SPI | 7789V | 230Cd/m3 | - 20~+70°C |
| 240RGB*320 |  |
QT-T20SH12KP01 | 2.00 | 35.7(H) x 51.2(V) x2.3Max(D) | 30.6(H) x 40.8(V) | 12pin | All View | 4 Line SPI | ST7789VW | 250Cd/m3 | - 20~+70°C |
| 240RGB*320 |  |
QT-T20ST22ZP02 | 2.00 | 36.05x51.8x2.45 | 30.6x40.8 | 22PIN | ALL VIEW | 8bit MCU 8080 | ST7789 | 200Cd/m3 | - 20~+70°C |
| 240RGB*320 |  |
QT-T20ST22ZP01 | 2.00 | 36.05(W)*51.8(H)*2.45(T) | 30.24(W)*40.32(H) | 22PIN | IPS-12 O’Clock | 8080 MCU 8 bits | ST7789V | 300-400Cd/m3 | - 20~+70°C |
| 128RGBx160 |  |
QT-T177NT12ZP01 | 1.77 | 33*42.46*2.35 | 28.03*35.04 | 12pin | TN-12 o`clock | SPI | ST7735S | 300-400Cd/m3 | - 20~+70°C |
| 128RGBx160 |  |
QT-T177NH14ZP02 | 1.77 | 34.70(H)*46.70(V)*2.3 | 35.04(H)*28.03(V) | 14pin | TN-12 o`clock | SPI | ST7735S | 300-400Cd/m3 | - 20~+70°C |
| 128RGBx160 |  |
QT-T177NH20ZP03 | 1.77 | 34.0(W)x43.7(L)x2.2 (T) | 35.04(H)*28.03(V) | 20pin | TN-12 o`clock | 80-system 8bits Parallel Bus | ST7735S | 250Cd/m3 | - 20~+70°C |
 |
